S2807 Brushless FPV Brushless Motor for Freestyle, Long-Range & Heavy-Lift Drones

The S2807 brushless FPV motor is a high-power, high-efficiency motor engineered for FPV freestyle, long-range drones, and heavy-lift UAV builds. Built around a true 28 × 7 mm stator with a 12N14P configuration, precision copper windings, and CNC-machined aluminum components, the SG 2807 delivers strong torque, smooth throttle response, and reliable thermal performance under demanding flight conditions.

Designed with tight manufacturing tolerances and a real 28 mm class footprint, this motor offers stable efficiency, low vibration, and secure prop mounting for aggressive flying and extended missions.

---

Technical Specifications :

Parameter

Specification

Motor Size	2807
KV Options	1300KV / 1700KV
Motor Configuration	12N14P
Stator Size	28 × 7 mm
Max Power	Up to 1160 W
Max Current	Up to 47 A
Weight	49 g (with cable)
Recommended Use	Freestyle FPV, Long-Range FPV, Heavy-Lift UAV

---

Key Features of the SG 2807 FPV Motor

• High-torque 12N14P brushless design for smooth and responsive control

• Optimized copper winding for improved efficiency and reduced power loss

• Precision-balanced rotor for stable flight performance

• Durable 5 mm (M5) steel shaft for high-load and aggressive flying

• Efficient heat dissipation for consistent power during long flights

• CNC-machined aluminum housing for strength and durability

---

Mechanical Dimensions :

Parameter

Specification

Motor Diameter	33.2 ± 0.1 mm
Motor Height	36.4 ± 0.3 mm
Shaft Diameter	5 mm
Shaft Thread	M5
Shaft Length	14.5 mm
Mounting Pattern	4 × M3
Base Diameter	Ø19 ± 0.05 mm

---

Why Choose the SG 2807 Brushless FPV Motor?

If you’re searching for a powerful 2807 FPV motor, a high-efficiency brushless motor for drones, or a reliable motor for 6S FPV builds, the SG 2807 is designed to exceed expectations. The combination of true 28xx geometry, precision machining, and high-torque output makes it ideal for pilots who demand strong thrust, precise control, and long-term reliability.

Whether you’re flying tight freestyle lines, carrying heavier payloads, or cruising long-range routes, the SG 2807 provides stable power, smooth response, and confidence in every throttle input.
